| • | Supply power | : | ~220V(+10%)/50Hz |
| • | Transfer | : | ~220V/24VDC 100W |
| • | Environment temperature | : | -20°C~+55°C |
| • | Protection fuse | : | 8A |
| • | Running time protection | : | adjustable |
| • | Auto closing delay time | : | adjustable |
| • | Force | : | adjustable |
| • | Duty Cycle | : | 25% |
| • | Power supply | : | 220v AC to the Control Panel |
| • | Power to motor | : | 24v DC |
| • | Gate weight | : | 300kg per leaf max. |
| • | Average power consumption | : | 1.7A |
| • | Motor rating | : | 40W max |
| • | Manual override | : | Via override keys supplied |
| • | Working temperature | : | -10 - +70 degrees |
| • | Actuator length when retracted | : | 740mm |
| • | Actuator length fully expanded | : | 1080mm |
| • | Maximum stroke | : | 300mm |
| • | Opening/closing running time | : | 12-15 seconds |
